Lifepo4 LFP Battery Cell 3.2 V 280ah 17472205mm Electric Vehicle Use

Name: Lifepo4 LFP Battery Cell 32 V 280ah 17472205mm Electric Vehicle Use
Brand: LS, LS
Price: 1 USD

Quality Lifepo4 LFP Battery Cell 3.2 V 280ah 174*72*205mm Electric Vehicle Use for sale

Brand Name : LS, LS

Certification : MSDS

Model Number : 0901024, 09010850

Place of Origin : China

MOQ : 4-63 Pieces

Price : Negotiable

Keywords : LiFePO4 Prismatic Cell

Product name : Li-ion Rechargeable Battery

Battery Size : 3.2v 280ah, 174*72*205mm

Weight : 5.2kg, 5.22KG

Battery type : LiFePO4

Nominal Capacity : 280AH

Discharge rate : 1-3C

Nominal Voltage : 3.2V

Cycle life : 3000 TIMES

Selling Units : Single item

Single package size : 20X25X12 cm

Single gross weight : 5.500 kg

Application : Home Appliances, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, Electric Folklifts, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Golf Carts, Electric Folklifts, e

Origin : Guangdong, China

Contact Now

LS 272Ah 280Ah 3.2V LiFePO4 Battery Prismatic Cells For Electric Vehicle

LiFePO4 Prismatic Cell Description:

LS 272Ah 280Ah 3.2V LiFePO4 battery square battery for electric vehicles, with overcharge and over-discharge protection, temperature control function short circuit protection, balance battery and ensure long battery life, LED power display and communication function.

LiFePO4 Prismatic Cell Parameter:

Keywords:	LiFePO4 Prismatic Cell	Product Name:	Li-ion Rechargeable Battery
Battery Size:	3.2v 280ah, 17472205mm	Weight:	5.2kg, 5.22KG
Battery Type:	LiFePO4	Nominal Capacity:	280AH
Discharge Rate:	1-3C	Nominal Voltage:	3.2V
Cycle Life:	3000 TIMES	Selling Units:	Single Item
Single Package Size :	20X25X12 Cm	Single Gross Weight:	5.500 Kg
Application:	Home Appliances, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, Electric Forklifts, Electric Vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Golf Carts, Electric Forklifts, E	Origin:

Rated capacity	280 AH
Internal impedance	0.1~0.3mΩ
Nominal voltage	3.2V
Dimensions(LWH)	17472205mm
Weight	5.22±0.2kg
Recommend Constant Curren	280A(1C)
End-of-Discharge Voltage	2.5V
Recommend Constant Current	140A(0.5C)
Charge Voltage	3.65V
Max Continuous Discharge Current	280A(1C)
Cycle life (80%DOD)	3000 cycles
Charging Temperature	-5~60°C
Discharging Temperature	-30~60

Over-Discharge Protection		Overcurrent Protection
Over-discharge detection voltage	2.2±0.05V	Overcurrent protection current	-
Over-discharge detection delay time	IMS	Overcurrent detection delay time	1s
Over-discharge release voltage	2.5±0.05V	Release condition	Cut short load

Short cycle protection		Temp. Protection
Detection condition	Out load short cycles	Charge protection Temp.	-5-50°C
Detection delay time	300±30	Discharge protection Temp.	-20-70°C
Release condition	Cut load	NTC thermal sensor

Self-consumption		Working Temp.
Current consumption in normal operation	<100uA	Temperature. range	-20/80℃
Sleep current(over-discharge)	≤20uA

LiFePO4 Prismatic Cell Factory Introduction:

Shenzhen Paisheng Import & Export Co., Ltd. specializes in the production of various 3.7V and 3.2V lithium-ion batteries, chargers, battery BMS and battery packs, etc. The products are widely used in digital products, laptop computers, electrical and electronic products, lighting equipment, toys, household appliances and emergency equipment. We have more than 10 years of battery manufacturing experience, we can assemble batteries and batteries according to your design and requirements.
